Chapter 9 Operational Settings

Appendix

Glossary

Introduction

Index

Contents

TOP

194

How to Load

Documents

Configuring the

Scan Settings

How to Use the

Operator Panel

Various Ways to

Scan

Daily Care

Troubleshooting

Replacing the

Consumables

Scanner

Overview

Operational

Settings

Scanning Thick Plastic Cards

[Feed Mode] (fi-7180/fi-7280)

When you use fi-7180/fi-7280 to scan at 300 dpi or less (80

ppm) in landscape, plastic cards with a thickness up to 1.4

mm can be scanned.

1 Start up the Software Operation Panel.

For details, refer to "9.1 Starting Up the Software Operation Panel"

(page 163).

2 From the listing on the left, select [Device Setting 2] 

[Feed Mode].

3 Specify the feed mode.

To scan a plastic card up to 1.4 mm thick, select [Thick cards (1.25

mm or more)].

Scanning at High Altitude [High Altitude Mode]

Select whether to enable or disable high altitude mode.

Enabling this setting allows you to use the scanner at 2,000 m

or higher altitudes.

1 Start up the Software Operation Panel.

For details, refer to "9.1 Starting Up the Software Operation Panel"

(page 163).

2 From the listing on the left, select [Device Setting 2] 

[High Altitude Mode].

3 Select whether to enable or disable [High Altitude Mode].

When you select [Enable], you can use the scanner at 2,000 m or

higher altitudes.

ATTENTION

Scanning speed slows down when you select [Thick cards (1.25

mm or more)].
