LQ038Q5DR01 Color TFT LCD Module (Model Number: LQ038Q5DR01) Specifications Spec No.: LCY-00044A Dated: May 31. 2002

LCY00044－7 7-2）Horizontal display position ①In case ENAB is active The horizontal display position is determined by ENAB signal and the in

LCY00044－8 （８）Input Signals, Basic Display Color and Gray Scale of Each Color Colors & Data signal Gray scale Gra

LCY00044－9 combination of total 18 bit data signals, the 262,144-color display can be achieved on the screen. （9）Optical characteristics Table 9-1

LCY00044－10 【Note 9-1】 Viewing angle range is defined as follows. 6 o ’ clock direction Normal line θ 2 θ 2 θ 12 θ 11

LCY00044－11 【Note 9-4】 Measured on the center area of the panel at a viewing cone 2°(= Filed) by TOPCON luminance meter BM-5A or ELDIM

LCY00044－12 （10）Mechanical characteristics 10-1）External appearance Do not exist extreme defects. (See Fig. 1) 10-2）Panel toughness

LCY00044－13 12-2）Precautions in mounting Polarizer which is made of soft material and susceptible to flaw must be handled carefully.

LCY00044－14 12-3）Precautions in adjusting module Adjusting volumes on the rear face of the module have been set optimally before shipment.

LCY00044－15 （15）Others Adjusting volume have been set optimally before shipment, so do not change any adjusted value. If adjusted value i

LCY00044－16 Reliability Test Conditions for TFT-LCD Module Table 14 Remark) Temperature condition is based on operating temperature conditions o

LCY00044－17 Fig.1. Outline Dimensions

LCY00044－18 Fig.2. Structure of the module

Horizontalsync. signal (Hsync)Clock signal (CK) Data signal(R0～R5,G0～G5, B0～B5)THcD1 D2 D3Tds TdhTch TclTcD319D320Horizontal invalid data periodHo

Horizontalsync. signal (Hsync)Clock signal (CK) Data signal(R0～R5,G0～G5, B0～B5)THcD1 D2 D3Tds TdhTch TclTcD319D320Horizontal invalid data periodHo

LCY00044-21 Fig.4.Packing form

SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.Suggested applications (if any) are for standard use; See Important Restrictions for limitations o

RECORDS OF REVISION ＭＯＤＥＬ Ｎｏ：ＬＱ０３８Ｑ５ＤＲ０１ ＳＰＥＣ Ｎｏ ：ＬＣＹ－０００４４ NO. PAGE SUMMARY NOTE 2000. 4.14 - - 1st Issue 2001. 6. 6 Ａ １ NOTICE

LCY00044－1 NOTICE This publication is the proprietary of SHARP and is copyrighted, with all rights reserved. Under the copyright laws, no part of

LCY00044－2 （1）Application This specification literature applies to color TFT-LCD module , LQ038Q5DR01. （2）Summary and Features ･This module is

LCY00044－3 （４）Input terminal 4-1）TFT-LCD panel driving part Used connector:KX14-40K5D1(JAE Co. , Ltd) Fit connect

LCY00044－4 【Note 4-1】 Hsync positive Vsync positive 【Note 4-2】 The horizontal display start timing is settled in accordance with a rising timing of E

LCY00044－5 （6）Electrical characteristics 6-1）TFT-LCD panel driving section Table 6-1 ＧＮＤ＝０Ｖ，Ｔａ＝２５℃

LCY00044－6 【Note 6-4】CK,R0～R5,G0～G5,B0～B5,Hsync,Vsync,ENAB,HVR 【Note 6-5】CK,R0～R5,G0～G5,B0～B5,Hsync,Vsync 【Note 6-6】ENAB 【Note 6-7】HVR 6-2）Backlig
