Sharp Electronics Corporation

Corporate Headquarters and Executive Ofﬁces

Sharp Plaza, Mahwah, New Jersey 07430-2135

www.sharpusa.com

For more information, call 201-529-8711 or fax 201-512-2040

Oven Capacity 1.1 cu. ft

Type of Oven/Control High Speed Convection with Microwave Auto-Touch

Controls

Cooking Uniformity Carousel

Turntable System with 13” diameter porcelain enamel turntable

Display 3-line 30 character lighted communication display

Oven Temperature Control 100º, 150º, 275º - 450ºF, in 25ºF, increments

Special Features Automatic Cooking (Convenience Appetizers & Snacks 17 options, Convenience

Meat, Fish and Poultry 16 options, Baked Goods 10 options, Basic Cook 17

options.) SelectaProgram 8 options for manual use. SelectaTime & SelectaPower

microwave time and 11 power levels. Custom Help, 6 options including sound

adjustment, memory check and counter check. Double/Triple Quantity. Oven

Ready On/Off keeps oven at 300ºF. Minute Plus, easy way to increase cooking time.

Color Stainless Steel (interior and exterior)

Output Power Microwave: 1000 watts

Heaters: Top: 1500W / Side: 1200W

Total: 2700 watts

Outside Dimensions (WHD) 21 5/8” x 16 1/2” x 23 1/4” (excluding handle)

21 5/8” x 16 1/2” x 25 1/4” (including handle)

AC Line Voltage 208 Volts, 20 Amps, 60hz, AC only

NEMA 6-20P/R

AC Power Required Microwave: 1800W 9.0 Amps

Convection: 3250W 16.0 Amps

Speed Cooking: 2900W 14.0 Amps

Approximate Weight Net: 86 lb

Shipping: 95 lb

Safety Compliance FCC, UL, DHHS, NSF-4

Included Accessories High rack, low rack, laminated touch guide

UPC Code 074000611856

To Specify a Sharp R-8000G Commercial High Speed Oven

Oven shall comply with standards set by the U.S. Department of Health and Human Services, FCC, NSF-4 and UL and shall display such labels. Oven shall be equipped with 10

programmable microprocessor-controlled Memory pads that can expand to 20 separate programs. Manual cook times can be programmed in one-second increments. Oven shall

have Electrically Alterable Read Only Memory (EAROM) to prevent selected programmed information from being erased due to power interruptions. Automatic cooking programs

include Convenience Appetizers & Snacks, Convenience Meat, Fish & Poultry, Baked Goods and Basic Cook. There are 8 options under SelectaProgram for manual use. Microwave

output wattage is 1000 watts. Top heater is 1500 watts and side heater is 1200 watts. Carousel turntable system provides uniform heating pattern. Oven shall be equipped with

SelectaPower control to provide 0 to 100 percent power in 10-percent increments. Oven shall have Oven Ready function to keep oven preheated to 300 F. Oven shall feature

Custom Help with 6 options for checking usage times as well as Demonstration Mode. Cavity will be stainless steel with an interior oven light. Turntable will be porcelain enamel.

Exterior will have a stainless steel see-through oven door and control panel. The outer cabinet will be stainless steel. Oven will have self-diagnostics for easier service. Voltage

required is 208. Oven will have a three-year limited warranty on the magnetron tube parts only and one year on parts and labor in the end user’s place of business.

Sharp Commercial Oven R-8000G is backed by a one year warranty for parts and

labor in the end user’s place of business. The warranty continues for an additional

two years for a total of three years with respect to the magnetron tube. Labor and

service are not provided free of charge for the additional period.

Speciﬁcations

21-1/4"

15-3/4"

21-5/8"

16-1/2"

11-5/8"

1-1/4"

20"

2-5/8" 16-1/2"

1-1/2"

2-7/8"

1-3/8"

5/8"

59"

Designs and speciﬁcations are subject to change without notice.

FRONT VIEW SIDE VIEW WITH DOOR OPEN REAR VIEW
