Specifications

Relevant signal timings (digital)

- Recommended resolution is 1024 x 768.

- All are compliant only with non-interlaced.

- A computer with an output terminal conforming to

DVI (DVI-D 24 pin or DVI-I 29 pin) and with XGA

output capability can be connected here.

(Depending on the type of computer to be

connected, the display may not work correctly.)

- If the monitor is receiving timing signals that are

not compatible, [OUT OF TIMING] will appear.

Follow your computer's instruction manual to set

the timing so that it is compatible with the

monitor.

- If the monitor is not receiving any signal (synch

signal), [NO SIGNAL] will appear.

US text

Screen resolution

Hsync Vsync

Dot

frequency

VESA

Relevant signal timings (analog)

- Recommended resolution is 1024 x 768.

- All are compliant only with non-interlaced.

- Frequencies for Power Macintosh are reference

values. To connect, another adapter

(commercially available) may be required.

- If the monitor is receiving timing signals that are

not compatible, [OUT OF TIMING] will appear.

Follow your computer's instruction manual to set

the timing so that it is compatible with the

monitor.

- If the monitor is not receiving any signal (synch

signal), [NO SIGNAL] will appear.

VESA

US text

Power

Macintosh

series

Hsync Vsync

Dot

frequency

Screen resolution
