1-5

Peripheral Equipment

The following options are available for using ZM-62E more effectively.

REC256F

ZM-71SE (Screen edit software for Windows98/NT4.0/Me/

2000/XP: English version)

Application software for editing display data for ZM series.

ZM-80C (Data Transfer Cable) 3m

Connects ZM-62E to a personal computer, or a personal computer to ZM-

1REC.

ZM-80PC (Printer Cable) 2.5m

Connects ZM-62E to a printer.

ZM-1REC (Card Recorder)

Reads display data created by personal computer, or works as an external

memory storage system for the memory manager and data logging func-

tions.

Memory Card on the market compliant

Used as a recording medium for display data back-up and for the memory

manager or data logging function.

ZM-1TC (Terminal Converter)

Used for connection between a ZM-62E and a PLC at the RS-422/485

terminal block.

1 System Composition

GPP

1 2 3

TB1

SW1

CN1

ZM-1MD2 (ACPU/QnACPU/FXCPU Dual Port Interface)

Add-on connector with two ports, specifically designed for the connector on

the MITSUBISHI's ACPU/QnACPU/FXCPU programmer. This can improve

operability of the ACPU/QnACPU/FXCPU programmer that is directly

connected.
