2-21

Using the Floppy Disk Drive Externally

To remove the floppy disk drive from the optional floppy disk drive box (CE-FC02),

release the lock latch on the base of the cover and pull the floppy disk drive out of

the box.

Release lock latch

on the base

Pull drive out of

box

To use the floppy disk drive as an external drive, follow the steps below:

Install the floppy disk drive into the floppy disk drive box. Simply slide the

drive in until it clicks into place.

Shut down your computer.

Plug the cable from the floppy disk drive box into the parallel/FDD port on the

rear edge of the computer.

Restart your computer.
