1-2

Battery lock button

Lower battery pack into

battery compartment

Battery pack

Battery release lever

Turn over your computer.

On the front edge of the computer, slide the cover latch to the right and raise the

cover.

Cover latch

Plug the cable from the AC adapter into the AC adapter jack on the rear side of

the computer.

Connect the power cord to the AC adapter.

1 2 ... 16 17 18 19 20 21 22 23 24 25 26 ... 106 107
