User’s Manual 6-1
Chapter 6
Power and Power-up Modes
The computer's power resources include the AC adaptor and internal
batteries. This chapter gives details on making the most effective use of
these resources including charging and changing batteries, tips for saving
battery power, and power-up modes.
Power conditions
The computer's operating capability and battery charge status are affected
by different power conditions, including whether an AC adaptor is
connected, whether a battery pack is installed and what the charge level is
for that battery.
Table 6-1 Power conditions
Power on
Power off
(no operation)
AC
adaptor
connected
Battery fully
charged
• Operates
• LED: Battery white
DC IN white
• LED: Battery white
DC IN white
Battery partially
charged or no
charge
• Operates
• Quick Charge
• LED: Battery amber
DC IN white
• Quick charge
• LED: Battery amber
DC IN white
No battery
installed
• Operates
• No charge
• LED: Battery off
DC IN white
• No charge
• LED: Battery off
DC IN white
