2. Lift the board straight up out of the computer.

Reverse this procedure to install the USB board.

System board

NOTE: All system board spare part kits include replacement thermal material.

Description Spare part number

System board for use in HP ProBook 6560b computers with discrete graphics:

HM65 with WWAN

● For use in all countries and regions except for Russia and the People's Republic of China 646963-001

●

For use in Russia and the People's Republic of China 653785-001

QM67 with WWAN

● For use in all countries and regions except for Russia and the People's Republic of China 646965-001

●

For use in Russia and the People's Republic of China 653787-001

For use in HP ProBook 6560b computers with UMA graphics:

HM65 with WWAN

●

For use in all countries and regions except for Russia and the People's Republic of China 646962-001

●

For use in Russia and the People's Republic of China 653784-001

HM65 without WWAN

●

For use in all countries and regions except for Russia and the People's Republic of China 654129-001

●

For use in Russia and the People's Republic of China 654305-001

106 Chapter 4 Removal and replacement procedures
