4.3 Memory Module 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-13
Installing the memory module
Before installing the memory module, confirm that the computer is not in stanby mode or
hibernation mode. Then perform the following procedure (See Figure 4-3, 4-4).
1. Insert the memory module into the connector of the computer slantwise (terminal
side first) and press it to connect firmly.
CAUTION:The power must be turned off when you insert a memory module. Inserting a
memory module with the power on might damage the module or the computer
itself.
When installing only one memory module, install it SLOT A. Otherwise, it
might damage the module or the computer itself
When installing a memory module, confirm that left anf right latches are
firmly locked a memor module.
2. Install the memory slot cover from the front side edge and secure it with the supplied
screw.
3. When the power of the computer is turned on, the computer checks automatically the
memory size. Confirm that the new memory is detected correctly.
4. If the memory is not detected, make sure it is connected surely.
