140 mm

148 mm

210 mm

600 mm

52 g/m²

157 g/m²

297 mm

210 mm

80 g/m²

3. Sending Documents

Transmittable Documents

Size and weight

The size and weight of documents that you can load in the document

feeder depend on whether you load one page at a time or several pages

at once.

Loading one page at a time:

Loading several pages at once:

Minimum

size

Maximum

size

Minimum

weight

Maximum

weight

Minimum

size

Maximum

size

Minimum

weight

Maximum

weight

140 mm

148 mm

52 g/m²
