<P=004>

Insert the large gear into the large holder on the imaging film

cartridge (make sure it clicks into place), and then insert the small

gear on the other end of the spool into its holder.

Cut the band that holds the two spools together. Unroll the film

slightly and insert the small gears into their holders.

Turn the cartridge over, grasp the handle, and insert the cartridge

into the print compartment.

1. Installation

Loading the Imaging Film
