<P=006>

Extension phone (optional)

If desired, you can connect an extension phone to the TEL. SET

socket on the fax.

♦

To connect an answering machine to your fax, see Chapter 6,

Answering Machine Connection

Remove the seal covering the TEL.

SET socket.

Connect the extension phone line to

the TEL. SET socket.

Important: In New Zealand, not all standard telephones and

answering machines will respond to incoming ringing when connected

to the extension socket of the equipment.

EL.

LINE

1. Installation

Connections
