Print Hold

Turning off the Print Hold function

In the event that you need to turn off the Print Hold function, follow the steps

below.

♦ The Print Hold function cannot be turned off if a received fax is being held

in memory by the Print Hold function. First print the fax and then turn off

Print Hold.

1 Press .

2 Press .

3 Press to select NO.

4 Press the numeric keys to enter the Print Hold code.

5 Press .

PRINT HOLD

START/

ENTER

Display:

PRINT HOLD

ENTER #(1-4, , )

4: ACTIVATE PRT. HOLD

1=YES, 2=NO

PRT. HOLD CODE=

ENTER PASSCODE #

1 2 ... 95 96 97 98 99 100 101 102 103 104 105 ... 147 148
