Distributed by:

AR-C172M

©SHARP CORP. (MAR. 2005) H1E Printed in Japan

AR-C172M

Digital Full Colour Multifunctional System

1,614 mm*

(63

638 mm*

(25

600 mm

(23

376 mm*

(14

676 mm

(26

1,180 mm

(46

Shown with options.

*1: 762 mm (30") with tray extended.

*2: 394 mm (15

") with multi-bypass tray extended.

*3: Max. 1,756 mm (69

") according to conditions *1 and *2.

JC172MF

SYSTEM CONFIGURATION

600 dpi

Printer board: Standard 128 MB, max. 640 MB

Hard disk: 40 GB

Windows

95/98/Me, Windows NT

4.0, Windows

2000/XP

Windows

2000 Server, Windows Server™ 2003;

Mac OS 8.6 to 9.2.2, Mac OS X 10.1.5, 10.2 to 10.3.4 (not 10.2.2)*

10Base-T/100Base-TX, USB 1.1, IEEE 1284 parallel port

Windows NT, NetWare, Macintosh

PCL5c, PS3*

80 fonts, 136 fonts for PS*

Power PC 7410-400 MHz

IPX/SPX for Novell environments,

TCP/IP for Windows and UNIX environments,

NetBEUI, AppleTalk for Macintosh environments*

Novell PSERVER/RPRINT for Netware, TCP FTP,

LRP/LPD for Unix, IPP 1.0, NetBEUI, AppleTalk printing*

RIP Once/Print Many, duplex print, N-up (2/4/6/8),

face up/down output, pamphlet style, margin shift, watermarks,

cover/transparency interleaving, fit to page, form overlay,

job control (confidential/hold/proof), print auditing

Desktop

Max. A3 wide (12" x 18"), min. A6R (5

" x 8

Plain paper: 64 to 105 g/m

(17 to 28 lbs.)

Heavy paper: 106 to 300 g/m

(28+ to 80 lbs.)

Standard: 750 sheets (500 + 250), max.: 5,750 sheets

40 sheets

Full colour: 17 cpm/ppm, B/W: 26 cpm/ppm

99 sec. or less

Full colour: 11.7 sec., B/W: 8.0 sec.

Rated local AC voltage ±10%, 50/60 Hz

1.44 kW (100V to 127V)

1.45 kW (220V to 240V)

670 x 676 x 787 mm (26

" x 26

" x 30

Approx. 75.5 kg (166.4 lbs.)

Original paper size

Continuous copy

Resolution

Memory

Gradation

Zoom range

Preset copy ratios

Features*

Max. A3 (11" x 17")

Max. 999 copies

Scan: 600 x 600 dpi, 600 x 300 dpi

Print: 600 x 600 dpi

256 MB (upgradeable to 512 MB with options)

Equivalent to 256 levels

50% to 200% in 1% increments, plus 25% and 400%

10 ratios (5 reduction + 5 enlargement)

8 ratios (4 reduction + 4 enlargement) in inch system

Scan Once/Print Many*

, electronic sorting,

auto paper selection, auto magnification selection,

paper type selection, auto tray switching, job memory (up to 10 jobs),

pre-heat/auto power shut-off modes, margin shift, edge/centre erase,

dual page copy, cover/transparency interleaving, mirror image,

multi-page enlargement, centering, image repeat, A3 wide (12" x 18")

printing, auto colour calibration/registration, rotation copy,

copy auditing (200 accounts), key operator programme,

multi-shot (4-in-1, 2-in-1), pamphlet copy, duplex copy,

B/W reverse, XY zoom, customised preset ratios (2R + 2E),

toner save mode (B/W), anti-counterfeit technology for bank notes

Network Printer

Resolution

Memory

Supported OS

Interface

Compatible networks

PDL emulation

Resident fonts

CPU

Network protocols

Printing protocols

Features*

Up to A3 size (11" x 17")

Push scan (via operation panel)

Full colour: max. 300 dpi (max. 600 dpi with additional memory)

B/W: max. 600 dpi

Scan to e-mail, FTP server, and desktop

Built-in address book, global address search (LDAP)

Colour: PDF, JPEG B/W: PDF, TIFF

TCP/IP (SMTP, FTP)

Sharpdesk™ ver. 3.1 with 10 user licenses

Network Scanner*

Scanning size

Scanning type

Resolution

Scan destinations

Destination selection

File formats

Network protocols

Bundled utility

*1: 300 g/m

paper can be used for simplex printing when fed through multi-bypass feeder. Duplexing is available for paper

weights up to 200 g/m

. Special paper, such as heavy paper weighing 201 to 300 g/m

, transparencies and envelopes, are

output face-up on the left tray. *2: 80 g/m

paper. *3: Copy mode: When copying same document continuously on A4

" x 11") plain paper in non-offset mode. Print mode: When printing same document continuously on A4 (8

" x 11")

plain paper in non-offset mode, excluding processing time. *4: Without auto paper select mode, portrait feeding of A4 (8

" x 11") sheets from 1st paper tray, output to side tray, group mode. *5: Some features require option(s). *6: Optional

memory required for duplex colour copying of documents B4 (8

" x 14") and larger in Quality mode (4-bit imaging).

*7: For colour network scanning, optional AR-NS2 (version 3.1 and later) and AR-SM5 (256 MB memory) required.

*8: Optional AR-PK4 and AR-SM5 x 2 required. *9: Some features are not available according to the printer driver used.

*10: Optional AR-FX10 required. *11: Based on Sharp’s standard chart with approximately 700 characters (A4 or 8

" x

11" portrait) at standard resolution in Super G3 mode, 33,600 bps, JBIG compression.

Facsimile (B/W)

Compression method

Communication protocol

Transmission time

Modem speed

Transmission resolution

Recording width

Memory

Greyscale levels

Features*

MH/MR/MMR/JBIG

Super G3/G3

Less than 3 seconds*

33,600 bps to 2,400 bps with automatic fallback

Standard: 203.2 x 97.8 dpi, up to 406.4 x 391 dpi (Ultra Fine)

A3 to A5 (11" x 17" to 5

" x 8

2 MB flash memory, 10 MB with option

Equivalent to 256 levels

Duplex transmission/reception, quick on-line transmission,

F-Code compatibility (confidential, relay broadcast), 500 rapid dials,

memory transmission/reception, timer transmission, broadcasting

(100 destinations), auto reduction (transmission/reception),

rotation transmission/reception, print actual size, polling,

job programme (up to 8), error correction mode,

anti-junk fax (50 numbers), long original transmission (max. 800 mm)

Type

Paper size

Paper weight*

Paper capacity*

RSPF capacity (max.)*

Print/copy speed (max.)*

Warm-up time

First copy time*

Power requirements

Power consumption (max.)

Dimensions (W x D x H)

Weight (main unit only)

(tentative)

SPECIFICATIONS

General

Copier

AR-LC8

3,500-Sheet

Large-Capacity

Tray

AR-RB1

Duplex Bypass/

Inverter Unit

AR-F13*

Saddle Stitch

Finisher

Allows automatic

stapling of up to

30 sheets and

folding and

stapling of

booklets of up to

10 sheets.

AR-TE3*

Exit Tray

AR-D17

Stand with 500-Sheet

Paper Drawer

AR-D18

Stand with 3 x 500-Sheet

Paper Drawers

AR-D19

Duplex Module with

2 x 500-Sheet Paper Drawers

*1: Can be used with or without AR-RB1. *2: AR-RB1 required when using AR-F13 or AR-D19

N. Some options may not be available in some areas.

AR-MM9

8MB Fax Memory

AR-FX10

Fax Expansion Kit

AR-PN1A/B/C/D

Punch Module for AR-F13

BASE UNIT

AR-NS2

Network Scanner

Expansion Kit (with

10 Sharpdesk licenses)

AR-U11M/U15M

Sharpdesk 1/5-License

Kit

AR-U1AM/U1BM

Sharpdesk 50/100-

License Kit

AR-PK4

PS3 Expansion Kit

AR-SM5

256MB Memory

AR-FR23

Data Security Kit

• Design and specifications are subject to change without prior notice.

• Some brand names and product names may be trademarks or registered trademarks of their

respective owners.

• The Energy Star logo is a certification mark and may only be used to certify products that have

been determined to meet the Energy Star programme requirements. Energy Star is a US

registered mark. The Energy Star guidelines apply to products only in the US, Europe,

Australia, New Zealand, and Japan.
