General Specifications

Type: AR-M162: Digital simplex copier-based MFP, desktop

AR-M207: Digital duplex copier-based MFP, desktop

Copy System: Dry electrostatic transfer system

Originals: Sheets, bound documents

Original Size: 11" x 17" maximum

Copy Size: Min. 5 1/2" x 8 1/2", Max. 11" x 17"

Copy Speed: 20/16 copies per minute (8 1/2" x 11")

15/12 copies per minute (8 1/2" x 11"R )

12/10 copies per minute (8 1/2" x 14")

10/9 copies per minute (11" x 17")

Continuous Copy: Max. 99 copies

First Copy Out Time: 7.2 Seconds (letter-size original, full ready condition)

Warm Up Time: 45 Seconds

Zoom Range: 25% to 400% in 1% increments (with SPF 50-200%)

Fixed Zoom Mode: 25%, 50%, 64%, 77%, 95%, 100%, 121%, 121%, 129%, 141%, 200%, 400%

Exposure System: Fixed optical source, slit exposure (stationary platen) with automatic exposure

Paper Feed System: Standard: AR-M162: 250 x 1

AR-M207: 250 x 2

Option: 250 x 1 or 250 x 2

Original Feed System: Standard: Original table with optional platen cover (AR-M162)

Optional: 40-sheet reversing single pass document feeder (RSPF) (AR-M207)

Optional 40-sheet SPF (AR-M162)

Electronic Sorting: Optional (Up to 100 sheets)

Paper Type: Paper Cassettes: 15-24 lb. standard or recycled bond paper

Bypass Tray (multi-sheet feed): up to 100 sheets 15-20 lb. standard bond or recycled

bond paper, up to 30 sheets for postcards, up to 5 sheets for envelopes (#10 monarch)

Bypass (single-sheet feed): 15-55 lb. standard or recycled bond paper, OHP, labels,

and envelopes

Copy Resolution: Scan: 600 dpi/Output: 600 dpi

Exposure Modes: Photo Mode: 600 x 600 dpi

Auto Exposure: 600 x 300 dpi

Gray Scale Output: 256 gradations/Scan: 2 levels

Copy Features: Auto Paper Sensing (APS), Auto Magnification Sensing (AMS),

auto tray switching, manual zoom

Output Tray Capacity: 250 sheets (face down)

Offset Stacking: Standard paper shifter

Fusing System: Heat roller

Developer System: Magnetic brush development

Light Source: Cold cathode lamp

Power Requirement: AC 120 V, 60 HZ, 12 Amps

Power Consumption: Max 1200 W, stand-by 5 W

Weight: AR-M207: Approx. 75.71 lbs./ AR-M162: Approx. 66.2 lbs.

Dimensions: AR-M162: 24" (w) x 24" (d) x 19" (h)

AR-M207: 24" (w) x 24" (d) x 21" (h)

Printer Function

Print Speed: AR-M162: 16 pages per minute

AR-M207: 20 pages per minute

Emulation: Standard host-based printing/Optional JBIG printing, PCL and PS3

Resolution: 600 dpi

Operating System: Windows

98, NT 4.0, ME, 2000, XP

Software: Print driver, Printer Status Monitor

RIP Once Print Many: Standard

Interface: Standard: IEEE 1284parallel port, USB 1.1/ Optional USB 2.0

Page Memory: AR-M162: 16 MB (shared), expandable to 288 MB with options

AR-M207: 32 MB (shared), expandable to 304 MB with options

Features: Offset print, status monitor, N-up printing, fit to page, watermark, center position

Color Scanner Function

Type: Flat head full color scanning system

Scanning Style: Platen/original feeder

Light Source: Cold cathode lamp

Resolution: Basic: 600 x 600 dpi

, setting range 50 – 9600 dpi

Original Type: Sheet/book

Scanning Method: Original cover/SPF (AR-M162)/RSPF (AR-M207)

Output: 1 bit/8 bit

Protocol: TWAIN, WIA (Windows XP)

Interface: Standard USB 1.1/Optional USB 2.0

Software: Sharpdesk Document Management Software, Composer

AR-EB9 Electronic Sort Board (Optional)

Standard Memory: 16 MB (approx. 100 pages)

Maximum Memory: 272 MB

Additional Features: Card Shot, USB 2.0 connctivity, JBIG enhanced PC printing

AR-FX11 Super G3 Fax Kit (Optional)

Transmission Mode: Super G3, G3

Modem Speed: 33.6 Kbps

Compression Methods: JBIG, MMR, MR, MH

Scanning Method: Sheet fed simplex (AR-M162), Duplex (AR-M207)

Max. Transmit Resolution: 400 dpi (ultra-fine)

Transmission Speed: Approx. 2 seconds with JBIG

Auto-Dialing Methods: 350 auto/group dialing destinations

Group Dialing: Up to 50 destinations

Broadcasting: Up to 200 destinations

Programs: 9 profiles

Memory: 2 MB standard/10 MB max. (8 MB option)

Halftone: 256 levels

AR-NB3 Network Expansion Kit (Optional)

Features: PCL6 network printing and network scanning with web-based management function

Standard Memory: 64 MB standard, expandable to 320 with 256 MB DIMM

Client PC Requirements: IBM PC/AT compatible (P3/500 MHz recommended), 100 MB available

hard disk space, and 800 x 600 dpi screen resolution

Operating Systems: Windows 95/98/ME/NT4/2000, Windows XP, Mac OS 8.6 – 9.2.2,

Mac OSX (excluding 10.2.2) (when using AR-PK1N Postscript Kit)

Network Protocols: TCP/IP, IPX/SPX (Netware), NetBEUI, and Ether Talk/AppleTalk

Interface: RJ45 Ethernet; 10/100baseT

Utilities Web-based management, NIC Manager, integrated software installer, Printer

Administration Utility (PAU), Printer Status Monitor, On-line manual

Print Emulation: PCL6/PCL5e/PS3 (option)

Print Speed: AR-M162: 16 ppm; AR-M207: 20 ppm

Print Resolution: 600 dpi

Print Features: 2-up/4-up printing, fit to page, auto paper select, booklet print,

direct print, watermarks, and duplex print (AR-M207)

Scanning Resolution: Up to 600 dpi

Operating Systems Windows 98SE/ME, 2000, XP

for Scanning:

Scanning Features: Scan to E-mail, Scan to Desktop, Scan to FTP, Scan to URL, and Scan to Print

Scanning Formats: TIFF, PDF, JPEG

Scanning Software: Sharpdesk (Version 3.1) document management software, includes OCR

and Sharp Composer (3-user license)

Optional Equipment

AR-SP6N: 40-sheet single pass feeder (AR-M162 only)

AR-RP6N: 40-sheet reversing single pass feeder (AR-M207 only)

AR-D24: 250-sheet paper feed unit (single cassette)

AR-D25: 500-sheet paper feed unit (dual 250-sheet cassettes)

AR-VR5: Platen Cover (standard on AR-M162)

AR-NB3: Network Expansion Kit

AR-PK1N: PS3 Expansion Kit (requires AR-NB3)

AR-EB9: E-Sort Board

AR-FX11: Super G3 Fax Kit

AR-TR4: Job separator Tray

AR-MM9: Fax memory

Supplies

AR-202MT: Toner Cartridge

AR-202MD: Developer

AR-202DR: Drum

Design and specifications subject to change without notice.

Sharp is a registered trademark of Sharp Corporation. All other

trademarks are property of their respective holders.

Can be expanded to 272 MB with 256 MB DIMM

With 256 MB memory expansion

Resolution settings higher than 600 x 600 dpi are interpolated

Based on ITU Test chart #1 in standard resolution, actual transmission time

will vary based on line conditions.

specifications

AR 162

AR 207

CPD-3705

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, NJ 07430-1163

1-800-BE-SHARP

www.sharpusa.com

As an ENERGY STAR

Partner, SHARP has

determined that this product meets the

NERGY STAR

guidelines for energy efficiency.
