5-6

CHAPTER5

MISFEED REMOVAL

COPIER TROUBLE? Misfeed removal

Roller rotating knob B

MISFEED HAS OCCURRED.

CLEAR INDICATED AREA.

PRESS FOR RECOVERY INSTRUCTIONS.

Close the paper tray and the side covers.

●

Confirm that the misfeed display is cleared.

Misfeed in the transport area, exit area and

fusing area

Open the front cover.

Turn the transport lever to the left.

●

Do not pull out the paper transport in this step.

Check to see if any paper is misfed in the exit area.

●

If any paper is misfed, turn roller rotating knob

in the direction

of the arrow to remove the misfed paper.

NOTE:

Be sure to turn roller rotating knob

only in the direction of the

arrow. If the knob is turned in the opposite direction, the copier may

malfunction.
