PLACING ORIGINALS

The automatic document feeder can be used to automatically scan many originals at once. This saves you the

trouble of manually feeding each original.

For originals that cannot be scanned using the automatic document feeder, such as a book or a document with

notes attached, use the document glass.

Using the automatic document feeder

When using the automatic document feeder, place the originals in the document feeder tray.

Using the document glass

Adjust the original guides to

the width of the originals.

Place the originals face up with the edges aligned

evenly.

The indicator line indicates approximately

100 originals.

The placed originals must not be higher than this line.

Place the original face down. Align

the top left corner of the original

with the tip of the mark in the

far left corner of the glass.

Place the original

face down.

To place a thick original such as a

book with many pages, push up the

far edge of the automatic document

feeder and then close the automatic

document feeder slowly.
