Advanced Features

Playback

47

Advanced Features

Selecting the Audio

Playback Mode

You can select any of the following audio

playback modes.

Audio 1+2

• 12-bit recording in stereo (Audio 1 and

Audio 2 channels)

• 16-bit recording in stereo (left and right

channels)

Audio 1

• 12-bit recording in stereo (Audio 1 channel

only)

• 16-bit recording in mono (left channel only)

Audio 2

• 12-bit recording in stereo (Audio 2 channel

only)

• 16-bit recording in mono (right channel

only)

1 Play back a Mini DV cassette with

dubbed audio.

2 Press the MENU button until the menu

screen appears.

3 Press l or m on the operation button

to select V, then press the SET button.

4 Press l or m to select “AUDIO”, then

press the SET button.

5 Press l or m to select the desired

audio playback mode, then press the

SET button.

6 Press the MENU button to turn off the

menu screen.

• The selected audio playback mode

indicator only appears when the on-

screen indicators are turned on.

Note:

• The audio playback mode indicator, “AUDIO”,

displays in different colours depending on the

recording mode (12- or 16-bit) used for the

recording being played back. A white display

indicates 12-bit recording mode, while a green

indicates 16-bit.

1

1

2

+

2

EFFECT

PLAYBACK

PIC.

AUDI O DUB

AUDI O

RETURN

SET

AUD I O

12

+

A UDIOAUDIO

21

+

21

+

Audio playback mode indicator

VL-NZ50E-E-042-047 02.4.8, 10:57 AM47
