SERVICE MANUAL

LC-32SB24U

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the

safety and performance of the set.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

SAFETY PRECAUTION

IMPORTANT SERVICE SAFETY PRE-

CAUTION ............................................................i

PRECAUTIONS A PRENDRE LORS DE

LA REPARATION ...............................................ii

OUTLINE AND MODIFIED PARTS LIST

OUTLINE ..........................................................iii

MODIFIED PARTS LIST...................................iii

Parts Guide

TopPage

CONTENTS

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-

inal condition and only parts identical to those specified should be used.

This Service Manual covers the differences from LC-32D44U. For other technical information, refer to the LC-32D44U

(No. SY7C1LC32D44U) Service Manual.

OUTLINE

No. S38H4LC32SB24

LCD COLOR TELEVISION

LC-32SB24U

MODEL
