FRONT TV

1. Main Power

On/Off Switch

2. Power Indicator

3. Program Selector

(UP/DOWN)

4. Volume Buttons

(UP/DOWN)

5. Remote Control Sensor

6. Sound Indicator

7. Remote Control Indicator

(Only for model 70GS-61S)

8. DOOR

Behind the door

9. Headphone Socket

(3.5 mm Ø / 16~600 Ω)

Controls & Terminals

REAR TV

RF Input

1. Antenna terminal

21-pin In/Out

2. 21-pin Euro SCART (RGB)

3. 21-pin Audio/Video (AV-1)

With S-Video Input

VIDEO AUDIO

L/S/G/I R/S/G/I

n

9

HOW TO OPEN THE DOOR

Press the top of the door, opening it slightly.

Hook your finger inside and pull open.

å

2

3

1

8

6 5 4 3 2 1

8

6

7

5 4 3 2 1

54GS-61S

70GS-61S
