fi-6130 / fi-6230 Image Scanner Operator's Guidefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP fi-6130 /

Conventions (2)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Conventions (2) 1 2 Screen Examples In

3.12 Color/Monochrome Auto Detectionfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.12 Color/Monochrom

3.12 Color/Monochrome Auto Detection The [Multi Image] dialog box appears. 5. Select [Auto Color Detection] under [Output mode].file:////10.232.

3.12 Color/Monochrome Auto Detection 6. Under [Select Current Image Setting], select a side, and then configure settings for each side in the [TWAI

3.13 Splitting a Page in Two Pagesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.13 Splitting a Page

3.13 Splitting a Page in Two Pages The [Option] dialog box appears. 5. Select the [Rotation] tab.6. Mark the [Split Image] checkbox. file:////10

3.13 Splitting a Page in Two Pages HINT When a double-sided document is scanned in Duplex mode, the scanned document image is output according to t

3.14 Removing Punch Holes from Imagesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.14 Removing Punch

3.14 Removing Punch Holes from Images The [Option] dialog box appears. 5. Select the [Rotation] tab.6. Select [Automatic Page Size Detection] or

3.14 Removing Punch Holes from Images 7. Select [Fill with white] or [Background color] from the [Hole punch removal] drop-down list. Fill with white

3.14 Removing Punch Holes from Images HINT Depending on the documents, characters and/or graphics may be mistakenly detected as punch holes and fil

Safety Precautions (1)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (1) 1 2 3

3.15 Scanning by Pressing the Scan Button on the Scannerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP

3.15 Scanning by Pressing the Scan Button on the Scanner The following events can be selected:● Scan Button (Press the [Scan] button)● Send to

3.15 Scanning by Pressing the Scan Button on the Scanner The [Setup] dialog box appears. 10. Select the [Event] tab.11. Click the action of the Ev

3.15 Scanning by Pressing the Scan Button on the Scanner HINT Use the [Send to] button, following the procedure below: 1. Press the [Function] butt

3.16 Splitting Documents by Patch Codefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.16 Splitting Doc

3.16 Splitting Documents by Patch Code HINT ● To suppress scanning the patch code sheet images, check the [Remove separation sheet] checkbox.●

3.16 Splitting Documents by Patch Code HINT When storing each of the scanned documents, which are separated with patch-code sheets, in separate fold

3.16 Splitting Documents by Patch Code All Rights Reserved. Copyright 2007-2008 © PFU LIMITEDfile:////10.232.227.50/Manual/fi-6130_6230_Lynx3L/OG/R0

3.17 Scanning Using Barcodesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.17 Scanning Using Barcodes

3.17 Scanning Using Barcodes 1. Create a new batch profile on ScandAll PRO, and open the [Profile Editor] window. For how to create a profile, see &q

Safety Precautions (2)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (2) 1 2 3

3.17 Scanning Using Barcodes ATTENTION ● If scanning performance deteriorates when barcode is used, reduce the detected barcode types or narrow

3.17 Scanning Using Barcodes HINT When storing each of the scanned documents separated with barcode-printed sheets in separate folders, and naming t

3.17 Scanning Using Barcodes All Rights Reserved. Copyright 2007-2008 © PFU LIMITEDfile:////10.232.227.50/Manual/fi-6130_6230_Lynx3L/OG/R02/02_08103

3.18 Not Detecting Multifeed for Fixed Formatfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.18 Not De

3.18 Not Detecting Multifeed for Fixed FormatAutomode 1 (Bypass by combination of length and position) When a Multifeed error occurs, press [Send to]

3.18 Not Detecting Multifeed for Fixed Format How to Configure Settings with Software Operation Panel 1. Open the Software Operation Panel.For detai

3.18 Not Detecting Multifeed for Fixed Format1. When the TWAIN driver is used; select [Use Memory on Scanner] or [Use both Memory] as [Cache Mode] on

3.18 Not Detecting Multifeed for Fixed Format Auto-cancel Timer: Scanning is not restarted for the set period of time (minutes) after a multifeed err

3.18 Not Detecting Multifeed for Fixed Format Multifeed errorNo sheets in the transport path"J" and "2" is indicated alternately→A

Chapter 4 DAILY CAREfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 4 DAILY CARE This chapter d

Safety Precautions (3)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (3) 1 2 3

4.1 Cleaning Materials and Locations Requiring Cleaningfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 4

4.1 Cleaning Materials and Locations Requiring Cleaning ATTENTION The scanner must be cleaned more frequently when the following documents are used:●

4.2 Cleaning the Flatbed [fi-6230 only]fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 4.2 Cleaning the

4.3 Cleaning the ADFfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 4.3 Cleaning the ADF As a Guideline

4.3 Cleaning the ADF No. Item1 Brake rollers (x 2)2 Feed rollers (x 2)3 Eject rollers (x 2)4 Glasses (x 2)5 Pick rollers (x 2)6 Plastic rollers (x 4)7

4.3 Cleaning the ADF Plastic roller Lightly clean the Plastic roller taking care not to damage the roller surface. Take particular care when cleani

4.3 Cleaning the ADF [Send to] Button [Scan] Button CAUTIONIn step 2, all the Feed rollers/Eject rollers turn at the same time. When cl

Chapter 5 REPLACING CONSUMABLESfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 5 REPLACING CONSU

5.1 Consumables and Replacement Cyclesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 5.1 Consumables an

5.2 How to Check and Reset the Consumables Countersfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 5.2 H

Safety Precautions (4)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (4) 1 2

5.2 How to Check and Reset the Consumables Counters 3. From the list on the left of the panel, select [Device Setting]. You can confirm the fo

5.2 How to Check and Reset the Consumables Counters 2. Click the [OK] button on the displayed confirmation message. The counter is reset to 0. (Th

5.2 How to Check and Reset the Consumables Counters Replace consumables when this message is displayed. When you click the [Ignore] button, this me

5.3 Replacing the Brake Rollerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 5.3 Replacing the Brake Ro

5.3 Replacing the Brake Roller 4. Remove the Brake roller from the shaft. 5. Attach a new Brake roller. Insert the shaft to the Brake rolle

5.3 Replacing the Brake Roller With the movie below, review the procedure to replace the Brake roller. 8. Reset the Brake roller counter. F

5.4 Replacing the Pick Rollerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 5.4 Replacing the Pick Roll

5.4 Replacing the Pick Roller1) Use the handle in the middle of the sheet guide to open it as shown below. Sheet guide 2) Rotate the Pick roller le

5.4 Replacing the Pick Roller5. Remove the Pick roller from the shaft. Remove the Pick roller from the shaft while lifting up the tab on the Pick rol

5.4 Replacing the Pick Roller 2) Rotate the Pick roller lever in the direction of the arrow.   Lever 3) Close the sheet guide. Make sure that bot

Chapter 1 NAMES AND FUNCTIONS OF PARTSfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 1 NAMES AND

5.4 Replacing the Pick Roller With the movie below, review the procedure to replace the Pick roller. 10. Reset the Pick roller counter. For how

Chapter 6 TROUBLESHOOTINGfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 6 TROUBLESHOOTING Thi

6.1 Removing Jammed Documentsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.1 Removing Jammed Documen

6.1 Removing Jammed Documents Press center of ADF ATTENTION● Make sure that the ADF is completely closed. When it is not completely closed, feed

6.2 Error Indications on the Operator Panelfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.2 Error Ind

6.2 Error Indications on the Operator PanelIndication Meaning RemedyJ1 Paper jam 1. Remove the halted or jammed document remaining inside. For how to

6.2 Error Indications on the Operator Panel Indication MeaningRemedyF4 Background switching mechanism error When you encounter this alarm on the displ

6.2 Error Indications on the Operator Panel Indication Meaning RemedyL6 Ultrasonic sensor error When a device alarm is indicated, turn the scanner of

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Trou

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

1.1 Checking the Contents of the Scanner Packagefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 1.1 Chec

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical TroublesIf you cannot solve the problem after taking measures, check the items in Section "6.4 Items to Check Before Contac

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical TroublesYESAre all the consumables (Pick rollers and Brake rollers) installed correctly? NOCorrectly install the consumables. (F

1.2 Names and Functions of Partsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 1.2 Names and Functions

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.3 Remedying Typical Troublesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.3 Remedying Typical Troubl

6.4 Items to Check Before Contacting the Dealer Where You Bought the Scannerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CO

6.4 Items to Check Before Contacting the Dealer Where You Bought the Scanner Installation or PC connection issuesProblem at the time of personal compu

6.4 Items to Check Before Contacting the Dealer Where You Bought the Scanner Imaging system troubleItem FindingsType and version of scanner driver Typ

6.5 Checking Labels on the Scannerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 6.5 Checking Labels on

Chapter 7 ADF AND PAPER SPECIFICATIONfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 7 ADF AND P

7.1 Document Sizefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 7.1 Document Size The following shows

1.2 Names and Functions of Parts No. Name Function1Document bed Place documents on the glass when scanning through the flatbed.2Document holding pad

7.2 Document Qualityfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 7.2 Document Quality Document Ty

7.2 Document Quality ATTENTION ● Carbonless paper contains chemical substances that may harm the Brake roller or paper-feeding rollers (e.g. Pick

7.2 Document Quality Dimensions: 3.4 inch (height) x 2.1 inch (width)/ 86 mm x 54 mm Thickness: 0.056 inches / 1.4 mm or less Material: PVC (Poly vin

7.3 Maximum Document Loading Capacityfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 7.3 Maximum Documen

7.4 Area Not to be Perforatedfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 7.4 Area Not to be Perforat

7.5 Multifeed Detection Conditionsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 7.5 Multifeed Detectio

7.5 Multifeed Detection Conditions All Rights Reserved. Copyright 2007-2008 © PFU LIMITEDfile:////10.232.227.50/Manual/fi-6130_6230_Lynx3L/OG/R02/02_0

Chapter 8 SCANNER SETTINGSfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 8 SCANNER SETTINGS T

8.1 Scanner Settingsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.1 Scanner Settings The Software

8.1 Scanner Settings Settings Using the Software Operation Panel, you can configure the following settings for the scanner connected to the PC

1.2 Names and Functions of PartsParts that can be removed from the scanner are displayed below. No. Name1ADF paper chute 2Pick roller 3Brake roller

8.1 Scanner Settings Selecting each item displays detailed settings (parameters) in the right part of the dialog box. Item Explanation Sel

8.1 Scanner Settings Document check area specification for Multifeed Detection Selected range: This is checked when limiting the range of detecting m

8.2 Power Saving Settingfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.2 Power Saving Setting This

8.3 Offset/Scan Scalefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.3 Offset/Scan Scale When the po

8.3 Offset/Scan Scale3. Adjust the Offset/Scan scale as necessary. Offset Setting Target Select ADF front, ADF back, or FB as target. H

8.4 Multifeed Detectionfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.4 Multifeed Detection "M

8.4 Multifeed Detection3. Select a detection option. None Does not detect multifeeds. Check Overlapping(Ultrasonic) Detects multifeeds by ch

8.4 Multifeed Detection 5. Speficy the detection range. Selected range To specify the following detection range, you need to mark this chec

8.4 Multifeed Detection Enable Enables the Multifeed Detection for the specified range. Start Specify the starting position of the detection ra

8.4 Multifeed Detection Unit: mm HINT When [Check Overrapping(Ultrasonic)] is selected, the multifeed detection ratio may drop if the document

CONTENTS MAPfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP CONTENTS MAP Back INTRODUCTION Regulat

1.3 Functions of the Operator Panelfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 1.3 Functions of the

8.5 Page Edge Fillerfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.5 Page Edge Filler Depending on

8.5 Page Edge Filler ADF FBT: Top edge=0 to 15 mm Top edge=0 to 15 mmD: Bottom edge=–7 to 7 mm Bottom edge=0 to 15 mmR: Right edge=0 to 15 mm Right

8.6 Dropout Colorfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.6 Dropout Color By using the “Drop

8.6 Dropout Color Red, Green, Blue Red, green, or blue is dropped out.None No color is dropped out. ATTENTION ● The Dropout Color setting can als

8.7 Pre-Pickfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.7 Pre-Pick To scan documents consecutive

8.7 Pre-Pick HINT ● By enabling Pre-Pick, faster scanning can be achieved.● While Pre-Pick is valid, if you cancel scanning in process, you h

8.8 Intelligent Multifeed Settingfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.8 Intelligent Multife

8.8 Intelligent Multifeed Setting Manual mode In this mode, when the scanner detects a multifeed and stops document feeding, you can reload the doc

8.9 Paper Feeding Retry Timesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.9 Paper Feeding Retry Tim

8.10 Life Counter Settingfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.10 Life Counter Setting Thi

1.3 Functions of the Operator PanelE F C H A L Indicates that an abnormality (alarm) occurred in the image scanner during its initialization or during

8.11 Timeout for Manual Feedingfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.11 Setting for Manual-F

8.11 Timeout for Manual Feeding HINT When the manual-feed timeout is enabled, the scanner waits for the document to be loaded within the specified

8.12 Power ON/OFF Control Settingfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 8.12 Power ON/OFF Contr

8.12 Power ON/OFF Control Setting3. To power on/off the scanner by pressing the Power button, select [Enable power switch]. To power on/off the scann

Chapter 9 SCANNER SPECIFICATIONfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 9 SCANNER SPECIFI

9.1 Basic Specificationsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 9.1 Basic Specifications Item

9.1 Basic SpecificationsOption Name: Black document pad [fi-6230 only] Parts No.: PA03540-D801 (Note (*9)) -Name: IMPRINTER [fi-6130 only] Parts No.

9.2 Installation Specificationsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 9.2 Installation Specifi

9.3 External Dimensionsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 9.3 External Dimensions The fol

APPENDIX 1 Before Using the [Scan] or [Send to] Buttonfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP AP

Chapter 2 BASIC SCANNER OPERATIONSfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 2 BASIC SCANNE

APPENDIX 1 Before Using the [Scan] or [Send to] Button The events available for this function are:● Scan Button (Press the [Scan] button)● Se

APPENDIX 1 Before Using the [Scan] or [Send to] Button 9. Click the [OK] button. HINT The window and operations may vary depending on your OS. Sett

APPENDIX 1 Before Using the [Scan] or [Send to] Button● When using the [Send to] buttonPress the [Function] button to switch the number displayed

2.1 Turning the Scanner ONfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 2.1 Turning the Scanner ON T

2.1 Turning the Scanner ON 3. Double-click the [Printer and Other Hardware] icon. The [Printer and Other Hardware] window appears. 4. Double-click t

2.1 Turning the Scanner ON 6. Click the [Device Set] tab. 7. Click the [Power Control] button. file:////10.232.227.50/Manual/fi-6130_6230_

2.1 Turning the Scanner ON The [Power Control] window appears. 8. Enable [Power Control]. Select [Enable power switch] to power on/off the sca

2.1 Turning the Scanner ON The Power Save mode keeps the scanner in a low-powered state after it has been turned ON. If no operation is performed on t

2.2 Loading Documents on the ADF for Scanningfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 2.2 Loading

2.2 Loading Documents on the ADF for Scanning HINT ● Pull out the paper chute extensions to support the document when necessary. Paper chute ex

CONTENTS MAPChapter 4 DAILY CARE 4.1 Cleaning Materials and Locations Requiring Cleaning4.2 Cleaning the Flatbed [fi-6230 only]4.3 Cleaning the ADF

2.2 Loading Documents on the ADF for Scanning Material: PVC (Poly vinyl chloride) or PVCA (Polyvinyl chloride acetate)Note: Before scanning your card,

2.2 Loading Documents on the ADF for ScanningWhen the document size to scan is A5 or longer in length When the document size to scan is A6 or longer i

2.3 Loading Documents on the Flatbed for Scanning [fi-6230 only]fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP T

2.4 Scanning Documentsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 2.4 Scanning Documents This sect

2.4 Scanning Documents 4. In the application, invoke a scanner driver. file:////10.232.227.50/Manual/fi-6130_6230_Lynx3L/OG/R02/02_081030/contents/

2.4 Scanning Documents 5. In the driver setup dialog box, configure settings for scanning. 6. Scan the document. 7. Save the scanned document

2.5 How to Use the Scanner Driversfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 2.5 How to Use the Sca

2.5 How to Use the Scanner Drivers Configure the FUJITSU TWAIN 32 Scanner Driver settings in the dialog box above. Major setting items are listed belo

2.5 How to Use the Scanner Drivers Black & White Documents are scanned in binary (black and white) mode.Halftone Documents are scanned through ha

2.5 How to Use the Scanner Drivers [Rotation] Tab Select this tab when configuring settings for the image rotation, document size and skew detectio

INTRODUCTIONfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP INTRODUCTION Thank you for purchasing the

2.5 How to Use the Scanner Drivers [Config] Button Click this button for configuring the Setting Files. You can save the changes made to a Setting

2.5 How to Use the Scanner DriversCamera You can selects a side or sides to scan. The marked checkbox side is targeted for scanning. When you mark onl

2.5 How to Use the Scanner DriversHalftone You can select a halftone pattern. This setting is available when [Black and White] is selected under [Mode

2.5 How to Use the Scanner Drivers Page Orientation You can select the page orientation (Portrait or Landscape). Page Size You can specify the pa

2.5 How to Use the Scanner Drivers [Image Processing] Tab Quick Setfile:////10.232.227.50/Manual/fi-6130_6230_Lynx3L/OG/R02/02_081030/contents/EN/

2.5 How to Use the Scanner Drivers Some image-processing-related settings, which are commonly used, are readily available. Select a setting pattern,

2.5 How to Use the Scanner Drivers Pre-pick Pre-picking is a function that prepares the next document for scanning, feeding it to the position at w

2.5 How to Use the Scanner Drivers Pattern You can configure gamma corrections. The gamma patterns include: Binary (black and white) specified Norm

2.5 How to Use the Scanner Drivers Color Dropout Any of three primary colors (red-green-blue) can be dropped out from document images. For example,

2.5 How to Use the Scanner Drivers JPEG Quality You can specify compression levels and image quality for scanning in Color or Grayscale mode. Sam

Regulatory Information (1)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Regulatory Information (1) 1

2.5 How to Use the Scanner Drivers [On] Checkbox Marking this checkbox enables the Imprinter function. Format Template Characters typed in this

2.5 How to Use the Scanner Drivers You can specify the rule to display the counter. Initial Value Set the initial value of the counter.Field Width Se

2.6 How to Use ScandAll PROfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 2.6 How to Use ScandAll PRO

2.6 How to Use ScandAll PRO HINT ● In ScandAll PRO, the default [Device Driver] is [TWAIN].● There is no functional difference between th

2.6 How to Use ScandAll PRO 1. From the [Scan] menu, select [Select Scanner].  The [Select Scanner] dialog box appears. 2. Select a scanner

2.6 How to Use ScandAll PRO For information about setting items you can configure, see Section "2.5 How to Use the Scanner Drivers." Ho

2.6 How to Use ScandAll PRO Or, select the [Scan Settings] button ( ) on the toolbar. The [Scan Settings] dialog box appears. 3. In the [Sc

2.6 How to Use ScandAll PRO To save scanned document images immediately after scanning, mark this checkbox. If you want to verify scans before sav

2.6 How to Use ScandAll PRO FUJITSU TWAIN 32 FUJITSU ISIS 6. When you finished setting, click the [OK] button in the dialog box (FUJITSU TWAI

2.6 How to Use ScandAll PRO HINT ● If you do not mark the [Save to file] checkbox in the [Scan Settings] dialog box, scanned document im

Regulatory Information (2)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Regulatory Information (2)

2.6 How to Use ScandAll PRO Or, click the [Batch Scan Settings] button ( ) on the toolbar. The [Batch Scan Setting] dialog box appears.

2.6 How to Use ScandAll PRO [General] Tab You can type in a profile name and description, and select a profile type. [Scan] Tab You can

2.6 How to Use ScandAll PRO You are returned to the [Batch Scan Settings] dialog box. Added or copied profiles by using the [Add] or [Copy] button ap

2.6 How to Use ScandAll PRO B: From the menu (Method 2) 1. Place the document on the scanner. For information about how to place documents, s

2.6 How to Use ScandAll PRO C: From the toolbar 1. Place the document on the scanner. For information about how to place documents, see Sect

2.6 How to Use ScandAll PRO All Rights Reserved. Copyright 2007-2008 © PFU LIMITEDfile:////10.232.227.50/Manual/fi-6130_6230_Lyn.../OG/R02/02_0810

Chapter 3 SCANNING VARIOUS TYPES OF DOCUMENTSfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 3 S

3.1 Scanning Both Sides of Documentsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.1 Scanning Both Si

3.1 Scanning Both Sides of Documents For information about how to scan documents, see Section "2.6 How to Use ScandAll PRO." Scanned docume

3.2 Scanning Books [fi-6230 only]fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.2 Scanning Books [fi-

Trademarksfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Trademarks TrademarksMicrosoft, Windows, Win

3.2 Scanning Books [fi-6230 only]5. From ScandAll PRO, display the setup dialog box of FUJITSU TWAIN 32. For information about how to display the sca

3.3 Scanning Large Documents with Flatbed [fi-6230 only]fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP

3.3 Scanning Large Documents with Flatbed [fi-6230 only] 6. Select [Flat Bed] under [Scan Type]. 7. Click the [OK] button. Changes made on this di

3.4 Scanning Documents of Different Widthsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.4 Scanning D

3.5 Scanning Documents Longer Than A4/Letter Sizefi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.5 Sca

3.5 Scanning Documents Longer Than A4/Letter Size 6. Click the [OK] button. Changes made on this dialog box are saved and the setup dialog box of

3.6 Saving Scanned Images in PDF Formatfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.6 Saving Scanne

3.6 Saving Scanned Images in PDF Format 1. Place the document on the scanner. For how to load documents on the ADF paper chute, see Section "2.2

3.6 Saving Scanned Images in PDF Format HINT [PDF file] and [SinglePage PDF file] are saved in format compatible with Adobe Acrobat 4.0 (PDF 1.3);

3.6 Saving Scanned Images in PDF Format Compression Rate Move the slider bar to change the compression rate. The compression rate can be changed

Liabilityfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Liability BEFORE USING THIS PRODUCT, PLEASE

3.6 Saving Scanned Images in PDF Format [Add a Document Open Password to created PDF files] Checkbox You can set a "Document Open&quo

3.6 Saving Scanned Images in PDF Format The [Acrobat Scan] dialog box appears. 4. Select [FUJITSU fi-6130dj] or [FUJITSU fi-6230dj] from the [Scann

3.6 Saving Scanned Images in PDF Format ATTENTION If scanned by using the default settings, images outputted may not be satisfactory. It is recommen

3.6 Saving Scanned Images in PDF Format 7. From the [File] menu, select [Save As] or [Save] to save the scanned images. For details on the operati

3.6 Saving Scanned Images in PDF Format 3. Click the [Properties] button.4. Select the [Adobe PDF Settings] tab.5. Select a desired setting from

3.6 Saving Scanned Images in PDF Format 6. Click the [OK] button.7. Click the [OK] button in the [Print] dialog box.8. Enter a file name, and then

3.7 Excluding a Color from Images (Dropout Color)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.7 Exc

3.7 Excluding a Color from Images (Dropout Color) The [Advance] dialog box appears. 5. Select a color you want to remove, from the [Dropout Color] d

3.7 Excluding a Color from Images (Dropout Color) 6. Click the [OK] button. You are returned to the [TWAIN Driver] dialog box. 7. In the [TWAIN D

3.8 Skipping Blank Pagesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.8 Skipping Blank Pages Blank

Conventions (1)fi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP Conventions (1) 1 2 Safety Precautions

3.8 Skipping Blank Pages 5. Select the [Job/Cache] tab.6. Mark the [Blank Page Skip] checkbox. If this checkbox is marked, cache mode is automatica

3.8 Skipping Blank Pages8. Click the [OK] button. You are returned to the [TWAIN Driver] dialog box. 9. In the [TWAIN Driver] dialog box, click the

3.9 Detecting Multifeedsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.9 Detecting Multifeeds "

3.9 Detecting Multifeeds 5. Select the [Job/Cache] tab.6. Select how to detect multifeeds from the [Multifeed Detection] drop-down list under [ADF O

3.10 Correcting Skewed Documentsfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.10 Correcting Skewed D

3.10 Correcting Skewed Documents5. Select the [Rotation] tab.6. Select [Automatic Page Size Detection] from the [Automatic Size and Skew detection]

3.10 Correcting Skewed Documents ATTENTION If one of the following conditions is met, the Automatic Page Size Detection may not work properly.● P

3.11 Outputting Multi-Imagesfi-6130 / fi-6230 Image Scanner Operator's Guide TROUBLESHOOTING CONTENTS MAP TOP 3.11 Outputting Multi-Images

3.11 Outputting Multi-Images The [Multi Image] dialog box appears. 5. Select [Multi Image Output] under [Output mode].file:////10.232.227.50/Man

3.11 Outputting Multi-Images 6. Select the order to output multi-images under [Order (for Multi Image Output)]. Primary: Color/Grayscale - Seconda
