44
REPLACING SUPPLIES AND MAINTENANCE
2
Open the front cover and remove the toner
collection container.
☞ Replacing the toner collection container (page 15)
3
Remove the cleaning tool for the writing unit from
the front cover.
mxc401_us_saf.book 44 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
