MAKING COPIES

Copying from the original table

COPYING FROM THE ORIGINAL TABLE

Two-sided copies from one-sided originals

Place the first original face down on the original table

and close the document feeder cover.

Use the ORIGINAL TO COPY key to select .

Ensure that the desired paper tray is selected.

●

Paper sizes that can be used in the duplex mode are 8-1/2" x 11", 8-1/2"

x 11"R, 8-1/2" x 14", and 11" x 17".

●

5-1/2" x 8-1/2" size paper cannot be used in the duplex mode.

●

The bypass tray cannot be used in the duplex mode.

Set the number of copies and press the START key.

●

The indicator will blink.

●

The copy will not be output until both sides have been scanned.
