Home screen Staple/sort finishing

Thumbnails

Saddle stitching (preview)

Preview

2-in-1 copying (preview)

Note: The screen shown above is just a sample.

Screen layouts and user interfaces can be

specifically designed to accommodate

customised application programmes.

Power save key

ENVIRONMENT &

USER-FRIENDLY

OPTIONS

ENVIRONMENTALLY ADVANCED

• Conforming to the ENERGY STAR

programme,

an international system identifying

energy-efficient products, the MX-M753N/M623N

has two levels of energy-saving modes to

reduce or shut off electricity after a period of

inactivity. Also, pressing the power save key

after a job is finished immediately puts the

MX-M753N/M623N into auto power saving

mode for further cutbacks on running costs.

8.5-Inch Touch-Screen LCD

The MX-M753N/M623N’s logically designed control panel features

a wide, clear, W-VGA-resolution touch-screen LCD with

easy-to-follow guidance. For example, when adjusting staple/sort

finishing or making pamphlets, the LCD displays step-by-step

instructions to guide you through the necessary procedures.

Pushing the Home button, even in the middle of an operation,

takes you back to the Start screen. Moreover, you can quickly

access the most frequently used functions and settings by

programming them into My Menu.

Thumbnail Display and Previews

Making the search for files easier and more convenient than ever,

thumbnails and up-close previews of Document Filing data files, as

well as conventional file names, can be displayed on the

MX-M753N/M623N’s LCD control panel. To help users decide

which documents to print out, the LCD can also display

thumbnails and previews of incoming faxes and Internet faxes. The

MX-M753N/M623N even prevents errors in copying, scanning, or

saving documents to its hard disk by showing previews of those

jobs on the LCD before actually executing them, making it easy to

confirm finishing options, scan settings, and other such items.

Environment Friendly

• With a standby power consumption of less than 1W in

night-time fax reception mode, the MX-M753N/M623N is one of

the leaders in the industry in energy savings for MFDs.

• The MX-M753N/M623N conforms to standards set for the

Nordic Swan European environmental label.

• In support of the RoHS directive, the MX-M753N/M623N are

fully compliant by restricting the use of hazardous substances in

their parts and materials.

EASY OPERATION

Specifications for Options

MX-FN14 Finisher (100-sheet staple)

Paper size Non offset A3 to A5R

Offset/staple A3 to B5

Max. paper capacity Upper tray 1,500 sheets (A4)

(80 g/m

) Lower tray 2,500 sheets (A4)

Middle tray* 250 sheets (A4)

Max. stapling capacity (80 g/m

) 100 sheets (A4 or smaller),

50 sheets (A4R, B4 or larger, or mixed)

Staple position 3 locations (front, rear, or both)

MX-FN15 Finisher

Paper size Non offset A3 to A5R

Offset/staple A3 to B5

Max. paper capacity Upper tray 2,000 sheets (A4)

(80 g/m

) Lower tray 2,000 sheets (A4)

Max. stapling capacity (80 g/m

) 50 sheets (A4 or smaller),

30 sheets (A4, B4 or larger, or mixed)

Staple position 3 locations (front, rear, or both)

MX-LCX3

N Large-Capacity Tray

Paper size A3 to B5

Paper capacity 3,000 sheets (80 g/m

)

MX-LC10 Large-Capacity Tray

Paper size A4, B5

Paper capacity 3,500 sheets (80 g/m

)

MX-CF10 Inserter

Paper size A3 to A5R*

Paper weight 60 to 256 g/m

Paper capacity 100 sheets (80 g/m

)

MX-FXX2 Fax Expansion Kit

Compression method MH/MR/MMR/JBIG

Communication protocol Super G3/G3

Modem speed 33,600 bps to 2,400 bps

Punch Modules

Model name

Number of holes

Paper weight

For the MX-FN14

MX-PN10A MX-PN10B MX-PN10C MX-PN10D

For the MX-FN15/16

AR-PN4A AR-PN4B AR-PN4C AR-PN4D

2 3 4 4 (wide)

56 to 256 g/m

System Configuration

MX-FN16 Saddle Stitch Finisher

Paper size Non offset A3 to A5R

Offset/staple A3 to B5

Max. paper capacity Upper tray 2,000 sheets (A4)

(80 g/m

) Lower tray 2,000 sheets (A4)

Saddle stitch tray

10 sets (11–15 sheets), 20 sets (6–10 sheets),

25 sets (1–5 sheets)

Max. stapling capacity (80 g/m

) 50 sheets (A4 or smaller),

30 sheets (A4, B4 or larger, or mixed)

Staple position 3 locations (front, rear, or both)

Sharpdesk 3.3 System Requirements

Supported OS Windows

XP (SP2) Professional/Home Edition, Windows Vista

, Windows 7

Hard disk Minimum requirement of operating system used plus at least 500MB to store Sharpdesk and Network Scanner Tool programmes

CPU Pentium

or equivalent processor (Windows XP: 800 MHz 32-bit/64-bit processor; Windows Vista and Windows 7: 1 GHz 32-bit/64-bit processor)

Memory Windows XP: 512MB RAM; Windows Vista and Windows 7: 1GB RAM/2GB RAM (Windows 7 64-bit)

Monitor Windows XP: SVGA display; Windows Vista and Windows 7: Direct X9 support with 128MB video RAM

* Guaranteed punchable weight is 56 to 128 g/m

* Excluding A5 size

* Non-offset tray

Job Status Screen

Whether printing or copying, the control panel displays a list of all

jobs, showing you at a glance the jobs in progress and the position

of your job in the queue. With a few quick touches of the LCD

screen, the Priority Printing function lets you easily change the

job queue order or delete jobs that are no longer needed.

Retractable Keyboard (Option)

A full-size retractable

QWERTY keyboard slides

out from beneath the control

panel to make text input fast

and easy: convenient for

typing things like e-mail

addresses and messages, as

well as passwords for user

authentication.

Sharp OSA (Open Systems Architecture)

The MX-M753N/M623N supports the Sharp OSA* development

platform. This innovative technology allows users to interact with

critical business and network applications and/or external account

software right from the LCD control panel, offering a new realm

of control and convenience. Since Sharp OSA utilises

industry-standard network protocols, such as XML and SOAP, the

MX-M753N/M623N can easily integrate with document

management systems, enterprise resource planning software,

workflow applications, and more.

* Requires optional MX-AMX2 and/or MX-AMX3.

Available at a later date

MX-FR22

Data Security Kit

(Common Criteria validated)

MX-FR22U

Data Security Kit

MX-CF10

Inserter

MX-FN14

Finisher

(100-sheet

staple)

MX-FN16

Saddle Stitch

Finisher

MX-FXX2

Fax Expansion Kit

MX-LCX3

Large-Capacity Tray (A3)

MX-LC10

Large-Capacity Tray (A4)

MX-FN15

Finisher

BASE UNIT

Certain options may not be available in some areas.

MX-PKX1

PS3 Expansion Kit

MX-PUX1

XPS Expansion Kit

AR-PF1

Barcode Font Kit

MX-FWX1

Internet Fax Expansion Kit

MX-USX1/X5

Sharpdesk 1/5-License Kit

MX-US10/50/A0

Sharpdesk 10/50/100-License Kit

MX-AMX1

Application Integration Module

MX-AMX2

Application Communication

Module

MX-AMX3

External Account Module

MX-ARSMX3

Expansion Memory Board

MX-EBX3

Enhanced Compression Kit

MX-KBX2

Keyboard

MX-PN10A/B/C/D

Punch Module (for MX-FN14)

AR-PN4A/B/C/D

Punch Module (for MX-FN15/16)

AR-SU1

Stamp Unit
