Bypass tray

Place paper that is A5 (7-1/4" x 10-1/2") or smaller

in the horizontal orientation.

Only the address side of envelopes can be printed on.

Place envelopes with the address side face down.

Special types of paper that cannot be loaded in other trays can be loaded in the bypass tray.

For detailed information on the bypass tray, see "LOADING PAPER IN THE BYPASS TRAY" in the

User's Guide.

When loading A3W, A3, or B4 size paper, pull out

the tray extension.

The maximum number of sheets that can be loaded

in the bypass tray is approximately 100 for plain

paper and approximately 20 for envelopes.

The side to be

copied on must

be face down!

Example: Loading an envelope
