Sending Functions
Original Orientation
To send the document in the orientation that can be read properly, specify the upper orientation of original. To use
the functions below, select the orientation in which the original is set on the platen.
• 1-sided / 2-sided Selection
When placing the original on the platen
When placing the original on the document processor
Use the procedure below to select the orientation when placing the originals on the platen for sending.
1 Press the Send key.
2 Place the original.
3 Press the Function Menu key. Function Menu appears.
4 Press the U or V key to select [Orig.Orientation].
5 Press the OK key. Orig.Orientation appears.
[Top Edge Top] [Top Edge Left]
[Top Edge Top]
[Top Edge Left]
Function Menu:
a
b
*********************
2
Original Size
T
3
Original Image
T
[ Exit ]
1
Color Selection
T
Orig.Orientation:
a
b
1
c
Top Edge Top
*********************
2
*
d
Top Edge Left
