1-72
BEFORE USING THE MACHINE
11
Install the toner collection container.
☞
REPLACING THE TONER COLLECTION
CONTAINER (page 1-52)
12
Close the front cover.
Take care that your fingers are not pinched when closing the cover.
13
Turn on the power.
Switch the main power switch "ON" and press the [POWER]
key ( ) on the operation panel to turn on the operation panel
power.
(1)
(2)
DATA
