Sharp AR-C265P User’s Guide

241

CMYK ink simulations – CMYK source data

The ICC-based color matching system can be used to simulate

the output on commercial printing presses.

You can select from the ink types most commonly used in

different regions of the world:

• Euroscale – Europe

• SWOP – North America

• Toyo – Jap a n

To print CMYK Ink Simulations, you must use PostScript printer

driver supplied.

Although it is possible to perform CMYK ink simulations using

the Office Color options in the printer driver, we recommend

that you use the Graphic Pro color matching system to perform

CMYK ink simulations, as this provides additional controls,

such as using the “Preserve Black” feature, or specifying an

alternative printer output profile.

Instructions on how to apply Ink Simulations appear in the

next section (Windows page 242, Mac OS 9 page 243,

Mac OS X page 244).

1. CMYK data 4. Printed document

2. CMYK input profile 5. CMYK device you wish to simulate (e.g. SWOP

press)

3. Printer output profile 6. Leave on Auto or select your custom profile
