2-15

Expansion Bay

You can install the following units into the expansion bay:

CD-ROM drive

Floppy disk drive

Optional battery pack

Expansion bay cover

Changing Units

•

Be sure to turn off the computer before changing units, or the computer

may malfunction.

•

Be careful of the direction of units.

Turn off the computer and remove the AC adapter and all peripheral devices.

Turn the computer upside down on a flat surface.

Slide the lock; then slide the lever and remove the unit from the bay.

Lock

Lever

Insert the other unit, with projection part facing up, and slide the lock.

Lock

Projection
