Razor-Sharp Image Quality

The B400’s high-resolution 320 x 240 infrared

detector delivers 76,800 pixels.This, combined

with FLIR’s exclusive Advanced Signal Processing,

reduces image “noise”and produces razor-sharp

thermal images four times the resolution of

competing brands that use a 160 x 120 array.


, as they say, is everything!

anc

ed Optics

The B400 offers both Auto and Manual Focus,

making it easy for anyone to take razor-sharp

thermal images and helping those new to

infrared from taking out-of-focus images.

A powerful one-touch 8x continuous digital zoom

lets you zero-in to the optimal view, whereas

other cameras deliver only preset zooms.

Interchangeable Lenses

he B400 c

omes with a built-in standar

d 25° lens

with the option of adding on a 45° wide angle or

15° telephoto lens.

Thumbnail Image Gallery

An easy-to-access thumbnail image gallery is

available to help you quickly review your saved

ther

mal images t

o find the one y

ou w

ant –

a massiv

e convenience and time saver!

Touch Screen Technology

Touch Screen technology lets you save text,

markers or even sketches right with your thermal

images, directly on the camera right from the

work site. It’s like having a note and sketch pad

with you every time you turn on the camera –

increasing your productivity and the quality of

our reports.

1.3 M

ega P

isual Camera

Capture visible images at the same time you

capture your thermal image with a built-in 1.3

mega pixel digital camera. Includes a target

illuminator for low light situations. You can draw

markers using Touch Screen technology that

works directly on the visual image.

aximum C

onnec

tivity

Options: SD/Memory Card,

Audio,Video & USB

housands of images can be stored to a standard

removable SD Memory Card.Use the Audio port to

connect a headset and record voice comments

while y

ou w

k with the c

amer

a. Voice comments

e st

ored with the IR image and can be played back

using ThermaCAM® QuickReport or ThermaCAM®

Reporter. A standard Video port lets you display

your images in real-time with any number of off-the-

shelf video displays – ideal when working with a

team or showing thermal output to customers,

clients or superiors. A standard USB port allows for

automatic image download from the camera using

her

maC

AM Q

uickReport.

In-Camera Radiometric

JPEG Image Forma

The infrared image is more than just a picture.

All temperature data, object parameters, analys

is tools, voice and text comments are stored with

the infrared image,allowing for advanced post-

processing and report writing using ThermaCAM

uickReport (included) or FLIR’s Microsoft Word-

ased

her

maC

AM Reporter. Add voice

comments in the field using a headset. The B400

JPEG image format combined with FLIR’s versatile

PC software creates a powerful and unique

Thermography system that eases data collection

in the field.

Radiometric JPEG/Word®-

ompa

tible S

tware with

ell Check

The B400 comes with FREE QuickReport analysis

and reporting software. Simply drag-and-drop

thermal images to create reports quickly and

easily

. Optional Reporter software allows you to

transfer fully radiometric – or “live”– images into

Word so you can go back and edit reports, adjust

emp

tur

e span or change color palettes at any

time – cr

itic

al functionality if you intend to email

reports to peers, customers or superiors or simply

if you want to run Spell Check!

hermal Fusion Functionality

nterchangeable Optics

1.3 MegaPixel Visual Camera

Automatically Associates the Visual and Thermal JPEG Images

Includes FREE QuickReport Software for Analysis & Reporting

Compatible with Optional Microsoft Word®-Based ThermaCAM

Reporter Software w/Spell Check

Removable SD/Memory Card, USB & Video Out

Onscreen Thumbnail Image Gallery

5 Temperature Spots & Delta T Functionality

Touch Screen Technology Adds Markers, Draws Sketches

Auto or Manual Focus with 8x Continuous Digital Zoom

Auto Hot/Cold Spot & Audible/Visual Alarms

Large 3.5”Color LCD Display

High Thermal Sensitivity for Maximum Temperature Accuracy

Voice Annotation

Built-in LaserLocatIR™

Long 4-hour Battery with In-Camera Charging or Car Charger

Optics head & display screen are independently rotatable for

optimum viewing

At Under 2 pounds, this remarkable camera is no lightweight

Best Image Quality Plus More Features

Equals Better Value!

www.goinfrared.com/B400

Visual Image of Wall

Fusion Image Showing Missing Insulation

Infrared Image

Now with FLIR FUSION!

FLIR's new FUSION func

tionalit

y allows for easier identification and interpretation of infrared images. This advanced technology enhances the value of an infrared image

y allowing you to overlay it directly over the corresponding visible image. This functionality combines the benefits of both the infrared image and visual picture at the

push of a button. The B400 camera does this in real-time and the overlay function can be easily adjusted to suit any application such as electrical surveys, building

diagnostics,and mechanical inspections.

Up To 5 Temperature Spots &

Delta T Functionality

Temperature difference is the most frequently

used measurement parameter for assessing the

condition of electrical components and other

plant assets. Accurate temperature difference

information could determine if the color

variation detected with the camera represents a

normal operating condition or a problem that is

about to start a fire.

The B400 makes this information easy to see

and communicate with the Delta Temperature

mode. Just place a reference spot on a target

operating at normal temperature and another

on the target with elevated temperature. The

Delta Temperature Function immediately

displa

ys the difference between these two

targets on the image making it easy for you to

diagnose the severity of the problem. The

image can then be stored with these

measurements and incorporated into the

report. It’s the easiest and fastest way to

diagnose and report your IR findings.

Auto Hot/Cold Spot

& Audible/Visual Alarms

Seeing the hottest or coldest spot on the

thermal image is often a critical requirement.

FLIR’s advanced in-camera algorithms make this

normally time-consuming task a breeze. You

can even pre-set temperature triggers to sound

audible or show visible alarms,and the

advanced in-camera tools can identify

overheating circuits, missing insulation,

mechanical failures,water intrusion leaks and

literally “sound off” to alert you to a potential

problem with the target you are scanning.

Holster for

Portability and

Easy Access to

Camera

Target Illuminator

and

1.3 Mega Pixel

Visual Camera

Tiltable Optics

Reduces

Back and Arm

Strain

Touch Screen

Text/Sketch

Functionality

1 2

ThermaCAM 1
Equals Better Value! 2
