Sending a Fax by Automatic Dialling

Speed Dialling

Speed Dialling can be used to dial any number that has been stored for

Automatic Dialling.

Load the document(s).

The display will show:

Press the

SPEED DIAL

key and then

enter the Speed Dial number by

pressing the numeric keys.

•

To enter numbers 1 through 9, first

enter 0 and then the number.

(Example)

START

READY TO SEND

•

Set the resolution and/or contrast if

desired.

RESOLUTION/

RECEPTION MOD

Check the display. If the name or

number shown is correct, press the

START

key. (If not, press the

STOP

key and then repeat Step 2.)

SPEE

DIAL

all-Fo50A.book Page 50 Friday, October 1, 1999 5:32 PM
