Remove the new roll of imaging film from its packaging.

•

••

•

Do not yet remove the band that holds the rolls together.

Insert the large gear into the green end of the empty spool. Make

sure the two protrusions on the large gear fit firmly into the slots in

the end of the spool.

Insert the remaining three gears into the spools, making sure the

protrusion on each gear fits firmly into one of the slots in the end of

each spool.

•

••

•

If needed, pull the spools apart slightly to allow the gears to fit (the

band will stretch).

Protrusion

Slot

Large gear

Loading the Imaging Film
