Basic Operation

-51

Emphasizing Outlines

in the Image (DFC)

This function allows you to select features for

outlines in the image.

Select “DFC” in the “Specials” on the

“Picture” menu screen.

•“DFC” is switched by pressing .

➝For operating the menu screen, see

pages 42 to 45.

Description

Sharp default setting

Emphasize outlines a little

Emphasize outlines most

Selected Item

(OFF)

(Level 1)

(Level 2)

(Level 3)

Resetting All Adjust-

ment Items

This function allows you to reset all adjust-

ment items to the default setting.

Select “Reset” in the “Picture” menu on

the menu screen and press .

➝For operating the menu screen, see

pages 42 to 45.

XV_Z12000_E_US_p42_60.p65 03.9.24, 2:02 PM51
