REMOVING MISFEEDS

SADDLE UNIT

When a mark below blinks, a misfeed has occurred at that location.

X Transport area

Open the cover.

Pull the M1 lever up in the direction of

the arrow.

Remove the misfed paper.

When released, the M1 lever

automatically returns to its

original position.

Pull the M2 lever up in the direction of

the arrow.

Remove the misfed paper.

When released, the M2 lever

automatically returns to its

original position.

Move the M6 lever in the direction of the

arrow.

Transport area

Stapler section

(page 22)
