OPERATION PANEL

IMAGE SEND

HOME

DATA

LINE

DATA

READY

SYSTEM

SETTINGS

JOB STATUS

Job Status

MFP Status

020/015

005/000

010/000

Copying

Waiting

Special Modes

Plain

2-Sided Copy

Output

File

Quick File

Copy Ratio

Tray1

100%

A4R

Original

Paper Select

Auto

Plain

Exposure

Auto

IMAGE SEND

DOCUMENT

FILING

COPY

Ready to scan for copy.

Image send indicators

LINE indicator

This lights up during transmission or reception in fax mode. The indicator also lights up during

transmission in scan mode.

DATA indicator

When a received fax cannot be printed because of a problem such as out of paper, the indicator

blinks. The indicator lights steadily when there is data that is waiting to be transmitted.

Touch panel

Messages and keys

appear in the LCD

display.

Operations are

performed by

touching the keys

with your finger.

[JOB STATUS] key

Press this key to view the job

status screen. You can check

the status of jobs and cancel

jobs in the job status screen.

Print mode indicators

READY indicator

Print data can be received when

this indicator is lit.

DATA indicator

This blinks while print data is

being received and lights steadily

while printing is taking place.

[SYSTEM SETTINGS] key

Press this key to display the system settings screen. The

system settings can be adjusted to make the machine

easier to use, such as configuring paper tray settings and

storing addresses.

[HOME] key

Touch this key to display the home

screen.

The base screen of each mode is

opened from the home screen.
