AR-BC320 TROUBLESHOOTING 11 - 18

Main

code

Sub

code

Title

Improper combination of the TEL/

LIU PWB and the FAX soft switch.

F6 21 Display Lamp/Message

Phenomenon Detail Improper combination of

the TEL/LIU PWB and the

FAX PWB information (soft

switch)

Section FAX

Case 1 Cause The destination of the

installed TEL/LIU PWB

differs.

Check &

Remedy

Check the destination of

the TEL/LIU PWB.

Case 2 Cause The FAX PWB information

(soft switch) differs.

Check &

Remedy

Check the FAX PWB

information (soft switch).

Case 3 Cause TEL/LIU PWB abnormality

Check &

Remedy

Replace the TEL/LIU

PWB.

Main

code

Sub

code

Title

The FAX-BOX PWB is not one for

the AR-BC320. (FAX detection)

F6 97 Display Lamp/Message

Phenomenon Detail The Modem controller of

the FAX-BOX is not one for

the AR-BC320.

Section FAX

Case 1 Cause The FAX-BOX Modem

controller PWB information

(hard detection) is not for

the AR-BC320. (A Modem

controller PWB for the AR-

FX5/FX6 or the AR-FX8 is

used.)

Check &

Remedy

1. Check the FAX-BOX

MODEM controller.

2. Replace the MODEM

controller PWB with one

for the AR-BC320.

Main

code

Sub

code

Title

Improper combination of the FAX-

BOX destination data and the

main unit destination data

F6 98 Display Lamp/Message

Phenomenon Detail Improper combination of

the FAX-BOX destination

data and the main unit

destination data

Section FAX

Case 1 Cause Improper combination of

the destination written in

the EEPROM on the FAX-

BOX PWB and the main

unit destination data (set

with SIM 26-6).

Check &

Remedy

1. Check the destination of

the FAX-BOX.

2. Check the destination of

the main unit with SIM

26-6.

3. Use a proper

combination of the main

unit and the FAX-BOX.

Main

code

Sub

code

Title

ICU-PRT communication trouble

(ICU detection)

F9 00 Display Lamp/Message

Phenomenon Detail Communication

establishment error,

framing, parity, protocol

error

Section —

Case 1 Cause Defective connection of the

ICU/PRT PWB

communication connector,

defective harness between

the ICU PWB and the PRT

PWB, defective ICU PWB/

PRT PWB

Check &

Remedy

Check connection and the

harness between the ICU

PWB and the MFP PWB.

Check the machine earth.

Replace the ICU or the

PRT PWB.

Main

code

Sub

code

Title

PRT DRAM trouble

F9 01 Display Lamp/Message

Phenomenon Detail DRAM in the PRT PWB

cannot be accessed.

Section —

Case 1 Cause Defective DRAM, defective

installation of the DRAM

Check &

Remedy

Replace the DRAM. Check

connection of the DRAM.

Main

code

Sub

code

Title

NIC port check error

F9 03 Display Lamp/Message

Phenomenon Detail NIC port check error

Section —

Case 1 Cause Defective connection of the

NIC connector, defective

NIC PWB, defective PRT

PWB

Check &

Remedy

Check the NIC connector

again. Replace the HDD.

Replace the PRT PWB.

Main

code

Sub

code

Title

HDD trouble (PRT controller

detection)

F9 20 Display Lamp/Message

Phenomenon Detail The HDD (option) does not

operate normally in the

machine with the HDD.

Section —

Case 1 Cause Defective connection of the

HDD connector, defective

HDD, defective PRT PWB

Check &

Remedy

Check the HDD again.

Replace the HDD. Replace

the PRT PWB.
