CONVENIENT COPY FUNCTIONS

MARGIN SHIFT COPY

The margin shift function is used to automatically shift the text or image on the copy paper approximately 10 mm

(1/2") in its initial setting.

Touch the [MARGIN SHIFT] key in the

special modes screen.

The margin shift setting

screen will appear.

The margin shift icon

( , etc.) will also

appear in the screen to

indicate that the function

is turned on.

Select the shift direction.

Touch the [RIGHT],

[LEFT], or [DOWN] key.

The selected key will be

highlighted.

Adjust the shift width as needed and

touch the [OK] key.

Use the and keys

to set the shift width. The

shift width can be set

from 0 mm to 20 mm

increments of 1 mm (0"

to 1" in increments of

1/8").

Touch the [OK] key in the special

modes screen.

You will return to the main screen of copy mode.

Image shifted

to the right

Image shifted

to the left

Image shifted

down

Margin

One-sided copying

Two-sided copying

Image shifted

to the right

Margin

Image shifted

to the left

Margin

Image shifted

down

• Right, left or down can be

selected for the shift direction

as shown in the illustration.

• The shift width (margin) can

be set from 0 mm to 20 mm

increments of 1 mm (0" to 1"

in increments of 1/8").

• If [DOWN] key is selected,

set the original(s) so that the

margin to be increased is set

to the rear side of the RSPF

or the document glass.

MARGIN SHIFT

PAMPHLET COPY

RIGHT LEFT DOWN

About the steps that follow

If you are using the document glass, see page 22.

If you are using the RSPF, see page 23.

• When margin shift is selected, rotation

copying will not function.

• This feature cannot be used with paper that

is not a standard size.

• To cancel the margin shift function, touch

the [CANCEL] key in the margin shift

setting screen. (See the screen of step 3.)

SIDE 1

(0 20)

SIDE 2

OKCANCEL

10 10

Note
