TROUBLESHOOTING AND MAINTENANCE

158

Gently pull the TD (Toner/Developer)

cartridge out while pressing the lock

release button.

Remove the TD (Toner/Developer) cartridge from the bag. Hold

the cartridge on both sides and shake it horizontally four or five

times. Hold the tab of the protective cover and pull the tab to

your side to remove the cover.

While pushing the lock release

button, gently insert the TD (Toner/

Developer) cartridge until it locks

into place.

• After removing the TD cartridge, do not shake it or tap on it. Doing so

may cause toner to leak from the cartridge. Put the old cartridge

immediately in the bag contained in the box of the new cartridge.

• Dispose of the old TD cartridge in accordance with local regulations.

Lock release button

4 or 5 times

Lock release button
