General Information

Controls and indicators (continued)

(XL-MP444H)

! Rear panel

Reference page

1. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3. Subwoofer Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6. Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

7. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

! Front speaker

1. Tweeter

2. Woofer

3. Bass Reflex Duct

4. Speaker Wire

! Subwoofer

1. Sub Duct Pipe

2.Subwoofer

3. Speaker Wire

Front speaker grilles are removable:

Make sure nothing comes into contact with the

speaker diaphragm when you remove the

speaker grilles.
