E-6

ENGLISH

8

XL-UH2000H

Preparation for Use

System connections

Left speaker

Right speaker

Wall socket

(AC 230 V, 50 Hz)

Speaker connection

(see page 7)

AM loop aerialFM aerial

Make sure to unplug the AC power lead before any connections.

Aerial connection (see page 7)

AC power connection (see page 8)
