03/12/17 CD-MPX870 EN.fm

E-6

ENGLISH

CD-MPX870H

Preparation for Use

System connections

Left speaker

Right speaker

Speaker connection

(see page 7)

Aerial connection (see page 7)

Make sure to unplug the AC power lead before any connections.

FM aerial

AM loop aerial

AC power connection (see page 8)

Wall socket

(AC 230 V, 50 Hz)

Speaker light-up wire Speaker light-up wire
