3,48in

88,5mm

3,78in

96mm

7,94in

201,7mm

5,05in

128,3mm

12,42in

315,5mm

Lens support

Optional

Optical

axis

4,27in

108,5mm

4,02in

102mm

Optical axis

4,17in

105,8mm

For additional dimensions see page 1

Camera with Lens IR f=76 mm (6°) incl support

Sheet

Drawing No.

Size

Check

Drawn by

Denomination

4(4)

T126960

Basic dimensions FLIR Exx

CAHA

2012-04-18

R&D Thermography

Modified

1 2 3 4 5 6 7 8 9 10

1 32 54

Size

1:2

Scale
