LC-G5C26U

LC-G5C32U

SERVICE MANUAL

MODELS

LC-G5C26U

LC-G5C32U

LCD COLOR TELEVISION

In the interests of user-safety (Required by safety regulations in some countries) the set should be re-

stored to its original condition and only parts identical to those specified should be used.

CONTENTS

Page

» MODIFIED PARTS LIST .............................................................................................................................2

» IMPORTANT SERVICE SAFETY PRECAUTION ......................................................................................3

» SCHEMATIC DIAGRAM .............................................................................................................................6

» PRINTED WIRING BOARD ASSEMBLIES ..............................................................................................10

» PARTS LIST ..............................................................................................................................................14

SHARP CORPORATION

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

OUTLINE

This model is based on the LC-26GA5U/LC-32GA5U. This Service Manual covers the modifications alone. Please

refer to a LC-26GA5U/LC-32GA5U service manual about other point.

1 2 3 4 5 6 ... 12 13
